Medium Duty Aluminum Leg and Wheel Docks
Model:
7" tall aluminum frame offers superior strength and stability
- Superior strength with a 7” tall aluminum frame
- Easy to install — simple “J” style connecting bracket – adjoining frame drops into a bracket with no holes to line up
- Support stanchions built into the frame, for an obstruction-free dock edge
- Removable decking panels in Cedar, WearDeck™ or Aluminum (Ipe hardwood decking option also available)
- For a lighter duty option, see our Standard Duty Aluminum Leg and Wheel Docks
Medium Duty Aluminum Leg & Wheel Docks
Free Local Delivery or Pick-up & Save. Click for details.
4' × 8'
75 lbs.
$1,105
$1,395
$1,350
4' × 10'
89 lbs.
$1,265
$1,630
$1,575
4' × 12'
100 lbs.
$1,410
$1,879
$1,789
6' × 8'
93 lbs.
$1,435
$1,860
$1,760
6' × 10'
111 lbs.
$1,645
$2,195
$2,055
6' × 12'
125 lbs.
$1,840
$2,495
$2,330
3' × 3' triangle
30 lbs
$630
$665
$655
4' x 16'
156 lbs.
$2,500
$3,065
$2,960
6' x 16'
184 lbs.
$2,815
$3,695
$3,450
Price
$48 set of 2
Post Caps: $5.75 each / Aluminum Pipe $9.50 per foot (1-1/2” SCH #40)
$48 each (aluminum)
4 foot: $ 200 / 6 foot: $ 210 / 8 foot: $ 220 / 10 foot: $ 230
Overview
Our medium-duty aluminum frame leg and wheel docks offer superior strength and stability, featuring a 7″ tall aluminum frame and longer and wider sections than our standard duty frames. Easy to install, the support stanchions are built into the frame and flush to the sides of the dock, allowing for an obstruction-free dock edge and the bottom of the frame has a radiused edge for comfort when carrying sections.
Available in both 4-foot and 6-foot widths, these docks will provide you with many years of strong, stable, and durable enjoyment.
Details
Available in 4 and 6-foot widths. Choose from Cedar, Aluminum, or WearDeck (available in 3 stocked colors) decking.
To find out more and get a free quote, get started by completing our quote request – this set of questions helps our expert staff to make recommendations on the best products and dock layout for your specific site. Or if you’d prefer, call us at: 1 (800) 870-6756 (click here for locations and hours) to speak with one of our Sales Staff.
Decking Options
Cedar is a natural decking option that is naturally resistant to decay and insects. We use STK Western Red Cedar (Select Tight Knot Grade or Number 2). It is generally regarded as a high-quality choice for cedar, and any knots present are sound encased and tight. The wood is generally straight-grained and has a uniform, but rather coarse texture.
CONS: Over time, cedar will absorb moisture and weather to a soft silvery gray unless sealed with a preserving stain.
Aluminum resists the growth of mold and mildew and won’t rust, rot, split or stain. This painted then baked beige finish eliminates glare from the aluminum. The non-slip, rigid, surface is low-maintenance and cool to the touch. Color is Sherman Williams Beige.
CONS: Can sound metallic when walking on it, especially on our docks with removable panels.
WearDeck™ is a high density polyethylene resin with UV inhibitors. It is rated for ground and underwater contact and will not support mold or mildew growth. WearDeck’s 5/4″ thick deck board is rated to span joists 24″ on center with the highest live load capacity in the industry. Made in the USA and offers a limited lifetime residential warranty and 25 year commercial warranty. Stocked in 3 colors, with special order colors available.
CONS: Not a natural wood. Barefoot Collection The colors of the Barefoot Collection (A) Barefoot Grey and (B) Barefoot Sand reflect the sun’s rays off the surface of the board and reduce surface temperature by at least 30%.
Assembly Components
Dimensions
- Widths available: 4-foot and 6-foot widths
- Lengths available (leg docks): 8-foot, 10-foot and 12-foot lengths
- Lengths available (wheel docks): 16-foot length
- Frames include built-in sleeves for 1-1/2″ galvanized pipe (1-15/16″ outside diameter)
- Frame height: 7″ aluminum frame
Shipping
If you are located in the Northeast, we offer free Curbside Delivery or Pickup and Save. Please see full details and terms and conditions here.
We also offer dock delivery and installation – contact us today to get a cost estimate and install timelines.
Many of our docks can be shipped – please contact us for a quote for shipping to your location.
Reviews
Frequently Asked Questions
Can you help me with a layout for the dock system?
YES! You can either call us during business hours at 1(800) 870-6756, or simply fill out our Quote Request (yellow button at the top right of our website) with the specifics of your location and waterfront needs and one of our sales staff will contact you to help design the perfect waterfront.
What is the difference between Standard Duty and Medium Duty Aluminum Docks?
Our Standard Duty Aluminum Docks feature a 4.75″ frame height, and our Medium Duty Aluminum Docks feature a 7″ frame height and increased material thickness. Our Standard Duty docks come in 4′ widths, and up to 10′ length for leg docks, and a 12′ length for wheel docks. The taller frames on of the Medium Duty allow it to come in wider (6′) and longer sections (12′ leg dock and 16′ wheel dock).
Can you deliver the docks to me?
YES! We offer curbside delivery within the Northeast (as well as local pickup and delivery with installation).
You can read more about the different options here.
What if I need the product installed?
Stock installations typically have a 2–4 week lead time depending on weather, order backlog, and if the installation requires the use of our workboat. We have a service installation staff of approximately 20 employees with a variety of skills and background and are equipped to cover the entire Northeast with our products and services.
How far in advance should I plan my project?
Our stock products are typically available for pick up within 1-2 days, or can be delivered within a 1–3 week time frame. Custom projects should be planned well in advance. Time frames are affected by several factors such as product demand, permitting, manufacturing, service, and weather conditions.
Why should I order from The Dock Doctors® instead of my local dock dealer?
Our product prices are very competitive providing shipping from our manufacturing facility in Vermont. Most of our competitors’ products are manufactured and shipped from the Midwest requiring trucking to the Northeast.
